Ceramic Fiber Fabric / Aluminum Silicate Fiber Fabric
Introduction:
Ceramic fiber fabric, also named aluminum silicate fabric, Al2O3 content about 45%, is divided in to two types: glass fiber reinforced and stainless steel wire reinforced. Fire rating class A, long term use 1000℃ below.
It will prolong high temperature and heat insulation time, when ceramic fiber fabric by heat treating, or coated with vermiculite.
Application:
Large area industrial insulation, thermal radiation shielding protective clothing, coated fabric, fireproof curtain, flexible expansion joint insulated carpet, other industrial thermal insulation, heat insulation, fire resistance and protection.
Characteristics:
Heat and electric insulation, acid resistance, oil and water vapor corrosion resistance, resistance of aluminum, zinc and other non-ferrous molten metal etching, good tensile strength, low thermal conductivity, non-toxic.
Specification:
| Colour | White |
| Material | Aluminum silicate fiber |
| Thickness | 1.5mm-6mm |
| Density | 500-525 |
| 58±2 | |
| Latitude | 29±1 |
| AI2O3 | ≥45% |
| Burning Out Rate(1050%) | ≤18% |
| Thermal conductivity | 0.17-0.20W/MK（100℃） |
| Reinforcements | Stainless Steel Wire |
| Maximum temperature | 1260℃ |
| Working Temp | 1050℃ |
| Melting Point | 1720℃ |
| Incombustible | grade B |
